MN1330KV40

T-Motor

NEW MN1330 KV40

NEW MN1330 KV40

$1,099.00 USD
$1,099.00 USD
Sale Sold out

MN1330 KV40

Shipping: USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

Classic Silver-and-Black Motor Design Optimized for Heavy-Lift UAVs KV40

Voltage 24s
Max Thrust/Arm 75.4kg
Rated Thrust/Arm 35~38kg

Applicable Configurations

  • Multirotor 4-Rotor
  • Multirotor 6-Rotor
  • Multirotor 8-Rotor
  • Multirotor Coaxial

Core Applications

  • Heavy-Lift Logistics & Delivery
  • Fire Rescue and Emergency Supply
  • Agricultural and forestry crop protection and large-area spraying

Ultra-Long Service Life and High Reliability

  • ≥ 2000 hours MTBF
  • -30℃~55℃ Stable Operating Temperature

Dual Dust-Mesh Structure for Rotor and Stator

  • IP45 protection standard, balancing lightweight design with protective performance
  • IP-Rated Water
  • IP-Rated Dust

Effectively resists water spray or heavy rain, ensuring stable motor operation in various harsh weather conditions.

Integrated High-Efficiency Cooling System

  • Built-in one-piece die-cast cooling fin structure doubles the heat dissipation area; compared with traditional split cooling structures, it enables faster heat transfer and higher cooling efficiency, reducing winding temperature by 5~8℃

MN1330 Recommended Setup

  • Motor: MN1330
  • KV: 40
  • ESC: M200A 24S
  • Propeller: NS52

Customization Options

  • Tailored solutions based on your application and performance requirements
  • Flexible customization to meet specific needs and create greater value
  • Custom Coating
  • Custom Logo
  • Temperature Sensor
  • Custom KV
  • Custom Hole Pattern
  • Custom Cable Length
  • More Tailored Solutions

Detail information

Specifications

Technical Drawing

Specification

Model No. MN1330
Motor Size Φ150*65mm
Stator Technology 150℃ High Temperature-Resisting Coatings
Copper Wire 220℃ High Temperature Resistance
Magnet Level 180℃ High Temperature Resistance
Coil Insulation Test 1000V Withstand Voltage Test
IP IP45
Configuration 36N42P
Rotor Dynamic Balance Standard ≤30mg
Bearing Imported 6004ZZ
Output Shaft Diameter /
Wire Specification/Length Enameled Wire*150mm

Technical Parameters

KV Value 40
Idle Current (20V) 3.4A
Max Power (180s) 3400W
Internal Resistance 19.5mΩ
Rated Voltage (Lipo) 24S
Peak Current 177A
Max Thrust 75kg
Motor Weight (Incl. Cable) 2750g
Package Weight 3300g

Recommended Combinations

  • Motor: MN1330 KV40
  • ESC: M200A24S
  • Propeller: NS52x20
  • Rated Voltage (Lipo): 24S

Test Data

Type Propeller Voltage (V) Throttle Current (A) RPM Thrust (gf) Power (W) Efficiency (g/W) Torque (N·m) Operating Temperature (℃)
MN1330 KV40 NS52x20 92.00 40% 14.47 1253 14117 1331 10.61 8.36 117 (Ambient Temp: 25)
92.00 42% 16.79 1318 15722 1545 10.18 9.28
92.03 44% 19.32 1383 17409 1778 9.79 10.26
92.03 46% 21.84 1444 19026 2010 9.47 11.23
92.07 48% 24.86 1508 20768 2289 9.07 12.28
92.03 50% 28.14 1575 22744 2590 8.78 13.43
92.06 52% 31.77 1638 24669 2925 8.44 14.61
92.05 54% 35.51 1701 26689 3269 8.17 15.82
92.04 56% 39.40 1760 28741 3626 7.93 17.00
92.03 58% 43.97 1822 30880 4046 7.63 18.30
92.04 60% 49.17 1886 33219 4526 7.34 19.71
92.03 62% 53.92 1946 35520 4962 7.16 21.11
92.03 64% 59.27 2005 37880 5455 6.94 22.55
92.02 66% 64.90 2061 40141 5972 6.72 23.96
92.02 68% 71.24 2118 42579 6555 6.50 25.49
92.01 70% 77.88 2176 45454 7166 6.34 27.25
92.02 80% 112.91 2434 57770 10390 5.56 34.98
91.99 90% 146.21 2623 66784 13450 4.97 40.81
91.90 100% 177.03 2744 75415 16270 4.64 46.25

Notes: Motor temperature is the motor surface temperature after running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.)
