MN1325KV47

T-Motor

NEW MN1325 KV47

NEW MN1325 KV47

$1,079.00 USD
$1,079.00 USD
Sale Sold out

MN1325 KV47

Classic Silver-and-Black Motor Design Optimized for Heavy-Lift UAVs KV47

Voltage 24s
Max Thrust/Arm 68.0kg
Rated Thrust/Arm 30~32kg

Applicable Configurations

  • Multirotor 4-Rotor
  • Multirotor 6-Rotor
  • Multirotor 8-Rotor
  • Multirotor Coaxial

Core Applications

  • Heavy-Lift Logistics & Delivery
  • Fire Rescue and Emergency Supply
  • Agricultural and forestry crop protection and large-area spraying

Ultra-Long Service Life and High Reliability

  • ≥ 2000 hours MTBF
  • -30℃~55℃ Stable Operating Temperature

Dual Dust-Mesh Structure for Rotor and Stator

  • IP45 protection standard, balancing lightweight design with protective performance
  • IP-Rated Water
  • IP-Rated Dust

Effectively resists water spray or heavy rain, ensuring stable motor operation in various harsh weather conditions.

Integrated High-Efficiency Cooling System

  • Built-in one-piece die-cast cooling fin structure doubles the heat dissipation area; compared with traditional split cooling structures, it enables faster heat transfer and higher cooling efficiency, reducing winding temperature by 5~8℃

MN1325 Recommended Setup

  • Motor: MN1325
  • KV: 47
  • ESC: M200A 24S
  • Propeller: NS47

Customization Options

  • Tailored solutions based on your application and performance requirements
  • Flexible customization to meet specific needs and create greater value
  • Custom Coating
  • Custom Logo
  • Temperature Sensor
  • Custom KV
  • Custom Hole Pattern
  • Custom Cable Length
  • More Tailored Solutions

Detail information

Specifications

Technical Drawing

Specification

Model No. MN1325
Motor Size Φ150*61mm
Stator Technology 150℃ High Temperature-Resisting Coatings
Copper Wire 220℃ High Temperature Resistance
Magnet Level 180℃ High Temperature Resistance
Coil Insulation Test 1000V Withstand Voltage Test
IP IP45
Configuration 36N42P
Rotor Dynamic Balance Standard ≤30mg
Bearing Imported 6004ZZ
Output Shaft Diameter /
Wire Specification/Length Enameled Wire*150mm

Technical Parameters

KV Value 47
Idle Current (20V) 4.0A
Max Power (180s) 3400W
Internal Resistance 17.5mΩ
Rated Voltage (Lipo) 24S
Peak Current 170A
Max Thrust 68kg
Motor Weight (Incl. Cable) 2425g
Package Weight 2990g

Recommended Combinations

Motor MN1325 KV47
ESC M200A24S
Propeller NS47x18
Rated Voltage (Lipo) 24S

Test Data

Type Propeller Voltage (V) Throttle Current (A) RPM Thrust (gf) Power (W) Efficiency (g/W) Torque (N·m) Operating Temperature (℃)
MN1325 KV47 NS47x18 91.94 40% 15.46 1480 13813 1421 9.72 7.51 105 (Ambient Temp: 25)
91.96 42% 17.94 1557 15355 1650 9.31 8.33
91.96 44% 20.53 1634 16948 1888 8.98 9.18
91.99 46% 23.29 1705 18494 2142 8.63 10.03
91.95 48% 26.36 1781 20200 2424 8.33 10.96
91.98 50% 29.87 1859 21973 2747 8.00 11.92
92.00 52% 33.40 1931 23769 3073 7.74 12.90
91.96 54% 37.26 2005 25588 3426 7.47 13.91
91.96 56% 41.22 2074 27376 3791 7.22 14.90
91.93 58% 45.63 2146 29402 4195 7.01 16.01
91.94 60% 50.61 2220 31508 4654 6.77 17.17
91.94 62% 55.66 2288 33690 5117 6.58 18.37
91.91 64% 60.89 2356 35708 5596 6.38 19.49
91.88 66% 66.23 2420 37881 6085 6.23 20.67
91.88 68% 72.07 2485 40036 6622 6.05 21.88
91.94 70% 78.53 2554 42302 7219 5.86 23.13
91.90 80% 111.70 2850 52622 10265 5.13 29.03
91.92 90% 142.06 3039 61476 13058 4.71 34.10
91.86 100% 169.69 3177 68088 15587 4.37 37.93

Notes: Motor temperature is the motor surface temperature after running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.)
