MN1320KV49

T-Motor

NEW MN1320 KV49

NEW MN1320 KV49

$929.00 USD
$929.00 USD
Sale Sold out

MN1320 KV49

Price: $929.00

Shipping: USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

Classic Silver-and-Black Motor Design Optimized for Heavy-Lift UAVs KV49

Voltage 24s
Max Thrust/Arm 58.9kg
Rated Thrust/Arm 25~28kg

Applicable Configurations

  • Multirotor 4-Rotor
  • Multirotor 6-Rotor
  • Multirotor 8-Rotor
  • Multirotor Coaxial

Core Applications

  • Heavy-Lift Logistics & Delivery
  • Fire Rescue and Emergency Supply
  • Agricultural and forestry crop protection and large-area spraying

Ultra-Long Service Life and High Reliability

  • ≥ 2000 hours MTBF
  • -30℃~55℃ Stable Operating Temperature

Dual Dust-Mesh Structure for Rotor and Stator

  • IP45 protection standard, balancing lightweight design with protective performance
  • IP-Rated Water
  • IP-Rated Dust

Effectively resists water spray or heavy rain, ensuring stable motor operation in various harsh weather conditions.

Integrated High-Efficiency Cooling System

  • Built-in one-piece die-cast cooling fin structure doubles the heat dissipation area; compared with traditional split cooling structures, it enables faster heat transfer and higher cooling efficiency, reducing winding temperature by 5~8℃

MN1320 Recommended Setup

  • Motor: MN1320
  • KV: 49
  • ESC: M200A 24S
  • Propeller: NS45

Customization Options

Tailored solutions based on your application and performance requirements. Flexible customization to meet specific needs and create greater value.

  • Custom Coating
  • Custom Logo
  • Temperature Sensor
  • Custom KV
  • Custom Hole Pattern
  • Custom Cable Length
  • More Tailored Solutions

Detail information

Specifications

Technical Drawing

Specification

Model No. MN1320
Motor Size Φ150*56mm
Stator Technology 150℃ High Temperature-Resisting Coatings
Copper Wire 220℃ High Temperature Resistance
Magnet Level 180℃ High Temperature Resistance
Coil Insulation Test 1000V Withstand Voltage Test
IP IP45
Configuration 36N42P
Rotor Dynamic Balance Standard ≤30mg
Bearing Imported 6904ZZ
Output Shaft Diameter /
Wire Specification/ Length Enameled Wire*150mm
KV Value 49
Idle Current (20V) 3.2A
Max Power (180s) 2900W
Internal Resistance 20.5mΩ
Rated Voltage (Lipo) 24S
Peak Current 150A
Max Thrust 58kg
Motor Weight (Incl. Cable) 2070g
Package Weight 2640g

Recommended Combinations

Motor MN1320 KV49
ESC M200A24S
Propeller NS45x17.5
Rated Voltage (Lipo) 24S

Test Data

Type Propeller Voltage (V) Throttle Current (A) RPM Thrust (gf) Power (W) Efficiency (g/W) Torque (N·m) Operating Temperature (℃)
MN1320 KV49 NS45x17.5 91.94 40% 14.01 1553 12378 1288 9.61 6.54 93℃ (Ambient Temperature: 25)
91.95 42% 16.17 1633 13739 1486 9.24 7.26
91.98 44% 18.59 1712 15182 1710 8.88 8.03
91.98 46% 21.12 1787 16663 1943 8.58 8.80
91.98 48% 23.98 1865 18261 2206 8.28 9.64
91.99 50% 27.35 1946 20015 2516 7.96 10.57
92.00 52% 30.79 2023 21743 2832 7.68 11.52
91.98 54% 34.50 2099 23442 3173 7.39 12.44
91.98 56% 38.15 2170 25130 3509 7.16 13.35
91.94 58% 42.38 2242 27015 3897 6.93 14.37
91.94 60% 47.01 2318 28986 4322 6.71 15.44
91.93 62% 51.69 2389 30984 4751 6.52 16.51
91.94 64% 57.06 2458 32985 5246 6.29 17.60
91.95 66% 61.82 2521 34959 5684 6.15 18.68
91.95 68% 67.13 2587 37010 6173 6.00 19.80
91.90 70% 73.63 2653 39107 6767 5.78 20.98
91.91 80% 90.49 2830 44480 8323 5.34 24.07
91.93 90% 126.87 3108 54596 11662 4.68 29.84
91.81 100% 148.96 3218 58958 13675 4.31 32.44

Notes: Motor temperature is the motor surface temperature after running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.)
