MN1315KV100

T-Motor

NEW MN1315 KV100

NEW MN1315 KV100

$799.00 USD
$799.00 USD
Sale Sold out

MN1315 KV100

Shipping: USD200 Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

Classic Silver-and-Black Motor Design Optimized for Heavy-Lift UAVs KV100

Voltage 14s
Max Thrust/Arm 50.1kg
Rated Thrust/Arm 20~25kg

Applicable Configurations

  • Multirotor 4-Rotor
  • Multirotor 6-Rotor
  • Multirotor 8-Rotor
  • Multirotor Coaxial

Core Applications

  • Heavy-Lift Logistics & Delivery
  • Fire Rescue and Emergency Supply
  • Agricultural and forestry crop protection and large-area spraying

Ultra-Long Service Life and High Reliability

  • ≥ 2000 hours MTBF
  • -30℃~55℃ Stable Operating Temperature

Dual Dust-Mesh Structure for Rotor and Stator

  • IP45 protection standard, balancing lightweight design with protective performance
  • IP-Rated Water
  • IP-Rated Dust

Effectively resists water spray or heavy rain, ensuring stable motor operation in various harsh weather conditions.

Integrated High-Efficiency Cooling System

  • Built-in one-piece die-cast cooling fin structure doubles the heat dissipation area; compared with traditional split cooling structures, it enables faster heat transfer and higher cooling efficiency, reducing winding temperature by 5~8℃

MN1315 Recommended Setup

  • Motor: MN1315
  • KV: 100
  • ESC: M248A 14S
  • Propeller: VZ40

Customization Options

Tailored solutions based on your application and performance requirements. Flexible customization to meet specific needs and create greater value.

  • Custom Coating
  • Custom Logo
  • Temperature Sensor
  • Custom KV
  • Custom Hole Pattern
  • Custom Cable Length
  • More Tailored Solutions

Detail information

Specifications

Technical Drawing

Specification

Model No. MN1315
Motor Size Φ150*51mm
Stator Technology 150℃ High Temperature-Resisting Coatings
Copper Wire 220℃ High Temperature Resistance
Magnet Level 180℃ High Temperature Resistance
Coil Insulation Test 1000V Withstand Voltage Test
IP IP45
Configuration 36N42P
Rotor Dynamic Balance Standard ≤30mg
Bearing Imported 6904ZZ
Output Shaft Diameter /
Wire Specification/Length Enameled Wire*150mm
KV Value 100
Idle Current (20V) 5.7A
Max Power (180s) 3300W
Internal Resistance 7.5mΩ
Rated Voltage (Lipo) 14S
Peak Current 248A
Max Thrust 50kg
Motor Weight (Incl. Cable) 1780g
Package Weight 2400g

Recommended Combinations

  • Motor: MN1315 KV100
  • ESC: M248A14S
  • Propeller: VZ40x16.1
  • Rated Voltage (Lipo): 14S

Test Data

Type Propeller Voltage (V) Throttle Current (A) RPM Thrust (gf) Power (W) Efficiency (g/W) Torque (N·m) Operating Temperature (℃)
MN1315 KV100 VZ40x16.1 54.02 40% 25.84 1910 11792 1396 8.45 5.56 97 (Ambient Temp: 25)
54.02 42% 29.77 2004 13021 1608 8.10 6.15
54.03 44% 33.96 2097 14271 1835 7.78 6.74
54.10 46% 38.27 2185 15521 2070 7.50 7.33
54.07 48% 43.29 2282 16873 2341 7.21 7.98
54.05 50% 48.47 2372 18265 2620 6.97 8.64
54.04 52% 54.18 2461 19672 2928 6.72 9.31
54.07 54% 60.21 2549 21157 3255 6.50 10.01
54.03 56% 66.35 2630 22576 3585 6.30 10.68
54.05 58% 73.81 2719 24184 3990 6.06 11.46
54.08 60% 80.99 2801 25803 4380 5.89 12.24
54.08 62% 88.73 2882 27361 4798 5.70 12.99
54.09 64% 96.79 2961 28951 5235 5.53 13.75
54.09 66% 104.93 3034 30497 5676 5.37 14.50
54.08 68% 114.47 3111 32240 6191 5.21 15.32
54.10 70% 123.67 3181 33881 6690 5.06 16.12
54.14 80% 173.45 3489 41641 9391 4.43 19.89
54.11 90% 228.82 3730 48342 12382 3.90 23.22
54.13 100% 247.74 3799 50170 13411 3.74 24.17

Notes: Motor temperature is the motor surface temperature after running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation.)
